IWILLUNITED STATES
N5 Plus product view 1 of 6

Mini PCs

N5 Plus

N5 Plus: Intel Pentium J3710 (4 cores, 1.6GHz up to 2.64GHz) with 2x RJ45 LAN.

Request configuration and pricing.

Tell us the required configuration, quantity, application, delivery ZIP code, and timing. Technical sales will confirm compatibility, availability, lead time, shipping origin, and quoted pricing.

Request a Quote
  • Intel Pentium J3710 (4 cores, 1.6GHz up to 2.64GHz)
  • DDR3L 1600MHz memory up to 8GB
  • 4K display support (1x DP, 2x HDMI)
  • 2x RJ45 LAN
  • Fanless design
  • 2x 2.5" HDD + 1x mSATA

Platform overview

Built into your system, not just placed beside it.

The N5 Plus is a compact mini PC from the IWILL Mini PCs range, built around Intel Pentium J3710 (4 cores, 1.6GHz up to 2.64GHz). Connectivity centers on 2x RJ45 LAN. Typical deployments include workstation, CAD/CAM, video processing. Configuration, lead time, and US availability are confirmed per project; technical sales validates the exact build before issuing a written quotation.

Supported operating environments in source documentation

Windows 11 · Windows 10 · Linux (Ubuntu/Fedora)

Technical specifications

Processor
Intel Pentium J3710 (4 cores, 1.6GHz up to 2.64GHz)
Memory
1x DDR3L 1600MHz, up to 8GB
Networking
2x RJ45 LAN
Display outputs
1x DP, 2x HDMI (4096×2160)
Storage
2x 2.5" HDD + 1x mSATA
I/O
4x USB 2.0, 1x COM
Dimensions
134 × 126 × 38.5mm
Weight
0.7kg

Typical applications

Where it deploys

  • Workstation
  • CAD/CAM
  • Video processing
  • Gaming

Expansion & I/O

Room to configure

  • 2x 2.5" HDD slots
  • 1x mSATA

Documentation

Datasheets and manuals

N5-Plus Datasheet

datasheet

N5-Plus Technical Manual

manual
