IWILL ITPC-A600 – Industrial Panel PC
ITPC-A600: Celeron J6412 / i3/i5/i7 (10th–11th Gen).
Request configuration and pricing.
Tell us the quantity and what it is for. Technical sales confirms the configuration, availability, lead time, and pricing.
Request a QuoteCollect several models and request one combined quote.
- Technical sales replies within 1 business day · Mon–Fri, 9:00–17:00 ET
- +1 (321) 438-8133
- WhatsApp +1 (321) 438-8133
- Configuration validated before quoting
- Written quote with lead time & warranty terms
- Single evaluation units available
- Celeron J6412 / i3/i5/i7 (10th–11th Gen)
- 1x DDR4 2133/2400MHz memory up to 32GB
- 4x USB 3.0, 2x COM option
- 1x M.2 2280 SATA + 1x 2.5" HDD
- DC 9-36V with protection
- Panel mount design
Platform overview
Built into your system, not just placed beside it.
The ITPC-A600 is an integrated touch panel PC from the IWILL Panel PCs & HMI range, built around Celeron J6412 / i3/i5/i7 (10th–11th Gen). It runs from DC 9-36V with protection power. Typical deployments include control panel, SCADA, machine interface. Configuration, lead time, and US availability are confirmed per project; technical sales validates the exact build before issuing a written quotation.
Supported operating systems
Windows 10 · Windows 11 · Linux
Technical specifications
- Display outputs
- 17"
- Processor
- Celeron J6412 / i3/i5/i7 (10th–11th Gen)
- Memory
- 1x DDR4 2133/2400MHz, up to 32GB
- Storage
- 1x M.2 2280 SATA + 1x 2.5" HDD
- I/O
- 4x USB 3.0, 2x COM option
- Power input
- DC 9-36V with protection
- Dimensions
- 408.5 × 346 × 61mm
Operating environment
- Operating temperature
- -10°C to 60°C (14°F to 140°F)
- Storage temperature
- -20°C to 70°C (-4°F to 158°F)
- Humidity
- 5–95%
Typical applications
Where it deploys
- Control panel
- SCADA
- Machine interface
Expansion & I/O
Room to configure
- 1x M.2 2280 SATA
- 1x 2.5" HDD slot
