IBOX-1226

IBOX-1226: Intel Celeron J6412 (4 cores, 2.0GHz up to 2.6GHz) with 3x 2.5G LAN.

Request configuration and pricing.

Tell us the required configuration, quantity, application, delivery ZIP code, and timing. Technical sales will confirm compatibility, availability, lead time, shipping origin, and quoted pricing.

Request a Quote
  • Intel Celeron J6412 (4 cores, 2.0GHz up to 2.6GHz)
  • 3x 2.5G LAN
  • 4x COM ports
  • TPM2.0, watchdog, PXE boot
  • Fanless design
  • 1x HDMI, 1x DP

Platform overview

Built into your system, not just placed beside it.

The IBOX-1226 is a fanless industrial computer from the IWILL Industrial PCs range, built around Intel Celeron J6412 (4 cores, 2.0GHz up to 2.6GHz). Connectivity centers on 3x 2.5G LAN. Typical deployments include Serial Server, PLC Gateway, automation. Configuration, lead time, and US availability are confirmed per project; technical sales validates the exact build before issuing a written quotation.

Supported operating environments in source documentation

Windows 10 · Windows 11 · Linux

Technical specifications

Processor
Intel Celeron J6412 (4 cores, 2.0GHz up to 2.6GHz)
Memory
1x DDR4 3200MHz, up to 32GB
Networking
3x 2.5G LAN
Serial ports
4x COM
Storage
1x M.2 SATA + 1x 2.5" HDD/SSD
I/O
2x USB 2.0, 2x USB 3.0
Display outputs
1x HDMI, 1x DP (2.5G LAN)
Dimensions
186 × 140 × 66mm
Weight
1.5kg
Platform features
TPM2.0, watchdog, PXE boot

Typical applications

Where it deploys

  • Serial Server
  • PLC Gateway
  • Automation

Expansion & I/O

Room to configure

  • 1x M.2 SATA
  • 1x 2.5" HDD/SSD slot
