IBOX-1026 product view 1 of 6

Industrial PCs

IBOX-1026

IBOX-1026: Intel Celeron J4125 (4 cores, 2.0GHz up to 2.7GHz) with 2x 1000M LAN.

Request configuration and pricing.

Tell us the required configuration, quantity, application, delivery ZIP code, and timing. Technical sales will confirm compatibility, availability, lead time, shipping origin, and quoted pricing.

Request a Quote
  • Intel Celeron J4125 (4 cores, 2.0GHz up to 2.7GHz)
  • 2x 1000M LAN
  • 5x COM ports
  • 4K@30Hz display support
  • 1x HDMI, 1x VGA
  • Fanless design

Platform overview

Built into your system, not just placed beside it.

The IBOX-1026 is a fanless industrial computer from the IWILL Industrial PCs range, built around Intel Celeron J4125 (4 cores, 2.0GHz up to 2.7GHz). Connectivity centers on 2x 1000M LAN. Typical deployments include Serial Gateway, lightweight applications, Protocol Converter. Configuration, lead time, and US availability are confirmed per project; technical sales validates the exact build before issuing a written quotation.

Supported operating environments in source documentation

Windows 10 · Windows 11 · Linux

Technical specifications

Processor
Intel Celeron J4125 (4 cores, 2.0GHz up to 2.7GHz)
Memory
1x DDR4 2400MHz, up to 8GB
Networking
2x 1000M LAN
Serial ports
5x COM
Storage
1x M.2 2280 + 1x 2.5" HDD
I/O
4x USB 2.0, 2x USB 3.0
Display outputs
4096×2160@30Hz (1x HDMI, 1x VGA)
Dimensions
234 × 200 × 54mm
Weight
2kg

Typical applications

Where it deploys

  • Serial Gateway
  • Lightweight applications
  • Protocol Converter

Expansion & I/O

Room to configure

  • 1x M.2 2280
  • 1x 2.5" HDD slot

Documentation

Datasheets and manuals

IBOX-1026 Datasheet

datasheet

IBOX-1026 Technical Manual

manual
