IBOX-101 Plus product view 1 of 6

Industrial PCs

IBOX-101 Plus

IBOX-101 Plus: Intel Celeron J1900 (4 cores, 1.99GHz, 10W TDP) with 2x 1000M LAN.

Request configuration and pricing.

Tell us the required configuration, quantity, application, delivery ZIP code, and timing. Technical sales will confirm compatibility, availability, lead time, shipping origin, and quoted pricing.

Request a Quote
  • Intel Celeron J1900 (4 cores, 1.99GHz, 10W TDP)
  • 2x 1000M LAN
  • 2x COM ports
  • 1x HDMI, 1x LVDS
  • Fanless design
  • Compact enclosure

Platform overview

Built into your system, not just placed beside it.

The IBOX-101 Plus is a fanless industrial computer from the IWILL Industrial PCs range, built around Intel Celeron J1900 (4 cores, 1.99GHz, 10W TDP). Connectivity centers on 2x 1000M LAN. Typical deployments include IoT Gateway, Serial Server, lightweight industrial applications. Configuration, lead time, and US availability are confirmed per project; technical sales validates the exact build before issuing a written quotation.

Supported operating environments in source documentation

Windows 10 · Windows 11 · Linux

Technical specifications

Processor
Intel Celeron J1900 (4 cores, 1.99GHz, 10W TDP)
Memory
1x DDR3L SODIMM, up to 8GB
Networking
2x 1000M LAN
Serial ports
2x COM
Storage
1x mSATA + 1x 2.5" HDD
I/O
4x USB 2.0
Display outputs
1x HDMI, 1x LVDS
Dimensions
186 × 150 × 66mm
Weight
1.6kg

Typical applications

Where it deploys

  • IoT Gateway
  • Serial Server
  • Lightweight industrial applications

Expansion & I/O

Room to configure

  • 1x mSATA
  • 1x 2.5" HDD slot

Documentation

Datasheets and manuals

IBOX-101 Plus Datasheet

datasheet

IBOX-101 Plus Technical Manual

manual
