Industrial Motherboards
HI-J6412D26
HI-J6412D26: Intel Celeron J6412 (4C/4T, 2.0/2.6GHz, 10W TDP) with 2x Gigabit LAN (Intel I210).
Request configuration and pricing.
Tell us the required configuration, quantity, application, delivery ZIP code, and timing. Technical sales will confirm compatibility, availability, lead time, shipping origin, and quoted pricing.
Request a Quote- Intel Celeron J6412 (4 cores, up to 2.6GHz, 10W TDP)
- 1x DDR4 3200MHz SO-DIMM, up to 16GB
- Triple display: HDMI + DP + eDP/LVDS
- 2x Gigabit LAN (Intel I210)
- 6x COM (RS232/RS485/TTL)
- 2x USB 3.0 + 4x USB 2.0
- Compact size 148×102mm
Platform overview
Built into your system, not just placed beside it.
The HI-J6412D26 is an embedded industrial motherboard from the IWILL Industrial Motherboards range, built around Intel Celeron J6412 (4C/4T, 2.0/2.6GHz, 10W TDP). Connectivity centers on 2x Gigabit LAN (Intel I210). It runs from DC 12V power. Typical deployments include medical equipment, communication systems, industrial automation. Configuration, lead time, and US availability are confirmed per project; technical sales validates the exact build before issuing a written quotation.
Supported operating environments in source documentation
Windows 10 · Windows 11 · Linux
Technical specifications
- Processor
- Intel Celeron J6412 (4C/4T, 2.0/2.6GHz, 10W TDP)
- Memory
- 1x DDR4 3200MHz SO-DIMM, up to 16GB
- Networking
- 2x Gigabit LAN (Intel I210)
- Display outputs
- HDMI (4096×2160@30Hz) + DP (4096×2160@60Hz) + eDP/LVDS
- Storage
- 1x SATA 3.0 + 1x M.2 2242/2280 (SATA/NVMe)
- I/O
- 6x COM, 2x USB 3.0, 4x USB 2.0
- Dimensions
- 148 × 102mm (3.5")
- Power input
- DC 12V
Typical applications
Where it deploys
- Medical equipment
- Communication systems
- Industrial automation
- Integrated systems
Expansion & I/O
Room to configure
- 1x M.2 KEY-B (USB 3.0 + PCIe X1)
- 1x M.2 KEY-E (PCIe X1 + USB 2.0)
- 1x SATA 3.0
